Description
Machine Specs
| Operating weight | 16.000 kg |
| Engine | DL06 |
| Engine power | 102.2 kW / 137 HP at 2000 RPM |
| Main pumps max flow | 2 x 170 l/min |
| Number of cylinders | 6 |
| Travel speed (High / Eco / Low / Creep) | 37 / 32 / 10 / 3.5 km/h |
| Maximum traction force | 8100 kg |
| Buckets | 0.24 – 0.76 m³ |
| Sound level (internal / external) | 70 dB(A) / 101 dB(A) |
| Overall width | 2500 mm |
| Tail swing radius | 2205 mm |
| Overall height (Mono / Arti boom) | 3242 mm / 3242 mm |
| Overall length (Mono / Arti boom) | 7420 mm / 8010 mm |
| Bucket digging force | 10.2 t |
| Arm digging force (Std Front) | 6.69 t |
| Max. digging reach (Mono / Arti boom) | 7585 mm / 8210 mm |
| Max. digging depth (Mono / Arti boom) | 4490 mm / 5025 mm |
| Max. digging height (Mono / Arti boom) | 8195 mm / 9060 mm |
